Submersible Borewell pumps are best suited for 4" borewell made with superior quality raw material, unique design to ensure best in-class performance with lowest operating cost and zero maintenance for years. Matchless and unique hydraulic design of bowl, impeller and diffuser put together construct the pump most energy efficient.
Highly sophisticated engineering and State of the art manufacturing process results the world class quality and consistency.
Salient Features
- Hydraulic compact and high efficient design saves electricity by 20% to 40% as compared to old conventionally designed pumps.
- Hydraulic, highly efficient design of Pump bowls.
- Lip seal and Sand guard prevents ingress of impurities into motor.
- Engineering Glass filled Plastic Bowl set with both side of S.S. Neck Rings.
- Impeller and diffusers are of special engineering plastic and increase the wear resistance towards sand.
- AISI 410 S.S. Sleeves are reinforced with chromium for proven wear resistance.
- Special LTB-4 and Nitrile Rubber Bush for proven anti-wear resistance.
- Pure AISI 410 S.S. Grade Pump Shaft
- Suction and NRV are of C.I. FG-200 / FG-220 Grade
- Max. Sand quantity into the water: 50 g/m.
| PUMP TYPE | H.P. RANGE | HEAD RANGE (Mtrs) | DISCHRGE (LPM) |
|---|---|---|---|
| V4 Bore Well | 0.5-5.0 | 30-220 | 50-230 |
Motor Specification
| Motor Body | S.S. With 1% Nickel |
| Stamping | Electrical Grade Silicon Steel Sheet With 3.9 to 4.5 watt loss/hour |
| Thrust Bearing | S.S. 304 Tilting pad Segment with Carbon Plate. |
| Bush | G.M. LTB 5 and Nitrile Rubber |
| Rotor Shaft | S.S 410 Grade high Tensile |
| Seal | Nitrile Rubber oil seal |
| Winding | poly propylene double coated copper wire |
| Copper Rotor | Grinding |
| Balancing | |
| Burnishing |
PUMP Specification
| Pump Bowl | Glass filled Plastic Bowl |
| Pump Shaft | S.S. 410 |
| Impeller | Glass filled Plastic Impeller |
| Pump Sleeve | S.S. with Hard Chrome Plating |
| Hardware | S.S 304 |
| DO | C.I DO WITH METAL BUSH |
