Submersible Borewell pumps are suitable for 6" bore well made with superior quality raw material & unique design to ensure best in-class performance with lowest operating cost and zero maintenance for years. Matchless and unique hydraulic design of bowl, impeller and diffuser put together construct the pump most energy efficient.
Highly sophisticated engineering and State of the art manufacturing process results in consistently offering world class quality.
| PUMP TYPE | H.P. RANGE | HEAD RANGE (Mtrs) | DISCHRGE (LPM) |
|---|---|---|---|
| 40 FEET | 3.0-25.0 | 20-330 | 35-1000 |
Salient Features
- Hydraulic, compact and highly efficient design saves heavy electricity in comparison to old conventionally designed pumps.
- Stainless Steel AISI - 304 Grade Investment casting nonmagnetic pump bowls.
- Stainless Steel AISI - 410 Grade pump impellers, available for mixed flow / radial flow.
- Stainless Steel AISI - 410 Sleeves are reinforced with chromium for proven wear resistance.
- Special LTB -4 and Nitrile Rubber Bush for proven anti-wear resistance.
- Pure Stainless Steel AISI 410 Grade Pump Shaft.
- Suction and NRV are C.I. FG-220 / FG-250 Grade.
- All rotating parts are dynamically balanced for low noise and longer bush bearing life.
- Motor body with stator varnished by vacuum impregnated plant to resist against corrosion & excessive heat in case.
- Internal surfaces of the all parts are protected from rusting with special coating for longer life.
- Light weight, hence easy to install and under water operation, so no noise.
- Better outer aesthetics with durable paint protection.
- Pump & Motor are packed with adequate fitments to avoid damage while reaching to end user.
- All components are machined on CNC machines with very close tolerances which reduces noise, vibration, wearing, current and heat ultimately product life. All fastness are used of stainless steel only for easy maintenance & very long life.
- Easily rewind able motor and fast maintenance with easily interchangeable spare parts.
- Higher efficiency results into high water discharge at low power consumption.
- Max. Sand quantity into the water: 50 g/m/
APPLICATIONS
- Irrigation (Sprinkler, Drip)
- Drinking water supply
- Farm House water supply
- Industrial water supply
- Cooling water systems
Motor Specification
| 40 FEET | |||
|---|---|---|---|
| Motor Body | S.S. 202 | ||
| Stamping | Jackson | ||
| Thrust Bearing | S.S. 304 Tilting pad Segment With Graded Super Teflon | ||
| Rotor Shaft | S.S 410 Grade High Tensile | ||
| Seal | Nitrile Rubber oil seal | ||
| Winding | Poly Propylene double Coated Copper Wire | ||
| Copper Rotor | Grinding | ||
| Balancing | |||
| Burnishing |
PUMP Specification
| Pump Bowl | Cast Iron |
| Pump Shaft | S.S. 410 |
| Impeller | S.S. 410 |
| Pump Sleeve | S.S. With Hard Crome Plating |
